Rubber-lined cross pipe fittings

LAD® - Rubber-lined products - Rubber-lined pipe fittings Series

This cross-pipe fitting is lined with a special rubber purchased from LAD Company, known for its high wear and corrosion resistance. The rubber lining is repairable, which helps to reduce maintenance costs.

BACK

Product Introduction
performance parameter

1.This cross-pipe fitting is lined with a special rubber purchased from LAD Company, known for its high wear and corrosion resistance.

2.The rubber lining is repairable, which helps to reduce maintenance costs.

Valve body material	Riveted carbon steel
Rubber composition	Natural rubber (black rubber), LNT (special red rubber from LAD), EPDM,butyl rubber, etc.
connection method	flanged
Applicable temperature	-30℃～+90℃，The maximum operating temperature can reach up to 150℃
Applicable medium	Air, water, slurry, seawater, hot water, weak acids, etc.
Caliber range	DN80～DN300(Larger calibers are available for individual customization.)
Flange Standard	National standard, German standard, Japanese standard, American standard, Russian standard, etc.
